Yaesu FT-991A vs Icom IC-9700
Home / Comparison tool / Yaesu FT-991A vs Icom IC-9700
Yaesu FT-991A or Icom IC-9700? I put both radios side by side: data from the manufacturers’ datasheets and photos at the same scale. Yaesu FT-991A has the edge: HF power, 6 m power, antenna tuner and weight; Icom IC-9700: 2 m power, 70 cm power, 23 cm power, second receiver, LAN / remote control, SD card, current draw on transmit and memory channels.
Specs side by side
| YaesuFT-991A▲ 4 | IcomIC-9700▲ 8 | |
|---|---|---|
| Bands and modes | ||
| Transmit bands | HF 1.8–29.7 MHz50–52 MHz144–146 MHz430–440 MHz | 144–146 MHz430–440 MHz1240–1300 MHz |
| Receive range | 0.03–56 · 118–164 · 420–470 MHz | 144–146 · 430–440 · 1240–1300 MHz |
| Modes | SSBCWAMFMC4FMRTTYPSK | SSBCWRTTYAMFMD-STAR |
| Transmit power | ||
| HF | 100 W ▲ | — |
| 50 MHz (6 m) | 100 W ▲ | — |
| 144 MHz (2 m) | 50 W | 100 W ▲ |
| 430 MHz (70 cm) | 50 W | 75 W ▲ |
| 1.2 GHz (23 cm) | — | 10 W ▲ |
| AM | 25 W | 25 W |
| Receiver | ||
| Construction | superheterodyne, triple conversion (FM: double) | SDR, direct RF sampling (23 cm: downconversion) |
| Second receiver | — | yes — two bands at once, full duplex (satellites) |
| Spectrum and waterfall | spectrum + waterfall | spectrum + waterfall, up to ±500 kHz |
| Features | ||
| Antenna tuner | HF + 6 m only | — |
| Display | 3.5″ colour touchscreen | 4.3″ colour touchscreen |
| LAN / remote operation | — | built-in LAN, RS-BA1, D-STAR gateway |
| USB | USB: CAT + audio | USB-B: CAT + audio |
| SD card | — | |
| Antenna connectors | SO-239 (HF/6 m) + N (2 m/70 cm) | SO-239 (2 m), N (70 cm), N (23 cm) |
| Power and case | ||
| Power | 13.8 V DC, external power supply | 13.8 V DC, external power supply |
| Transmit current draw | 23 A | 18 A ▲ |
| Dimensions | 229 × 80 × 253 mmwidth × height × depth | 240 × 94 × 238 mmwidth × height × depth |
| Weight | 4.3 kg ▲ | 4.7 kg |
| Other | ||
| Memory channels | 99 | 297 ▲ |
| Release | 2016 | 2019 |
Data: manufacturers’ spec sheets and manuals · as of 31.10.2026
